DÖME

DÖME Low-Level Gamma-Spectroscopy Facility

Instrument responsible: Zoltán Kis
Contact: dome@bnc.hu

The increasing need for low-background counting led to the installation of a permanent counting station in the cold-neutron guide hall of Budapest Neutron Centre in 2010. The purpose of DÖME (DÖgnehéz Mérő Eszköz or “damn heavy measuring tool”) is to assist the in-beam activation measurements with off-line counting option on a routine basis and to allow the measurement of environmental samples of low activities. The facility’s main features are instant and local availability and highly accurate activity measurement.

The low-level counting station consists of an iron chamber manufactured from pre-World War II iron (recycled material of the bombed Elisabeth-bridge, 1945), and is, therefore, free of any man-made radioactivity. The wall of the chamber is 155 mm thick and has a graded shielding (148.5 mm Fe, 5 mm Pb, and 1.5 mm Cu layers). The chamber with an internal dimension of 800×800×800 mm3 accommodates a Canberra GR1319 HPGe detector of 13% relative efficiency with a BigMAC cryostat along its horizontal diagonal. This geometry allows sample-to-detector distances up to 250 mm.

As an option for targeted measurements of low-energy lines, a Canberra Low Energy HPGe (GL1018) detector is also available with better energy resolution but for a narrower energy range (up to about 1 MeV). A Canberra DSA-2000 digital gamma spectrometer with 16k channels is used for the data collection. With the GR1319 detector, the facility has a spectral background of about 1.39 cps over the energy range of 7-3150 keV, which compares to 211 cps outside the chamber (i.e. a reduction factor of 152). Dead-time losses during the experiments are typically below 1%.

In-beam-activated powder samples can be measured in the Teflon bag used for the PGAA or NIPS-NORMA experiment. Solid samples can be analyzed as received. For powdered environmental samples an easily re-sealable, radon-gastight sample holder from high-density polyethylene was fabricated.

The three main parameters of the facility are detection efficiency, channel-to-energy calibration with nonlinearity, and energy resolution. These are established using commercially available certified radioactive sources (152Eu, 207Bi, 60Co, 133Ba, 226Ra). The system is calibrated for contact geometry as well as for 32, 167, and 237 mm distances. The Efficiency, Nonlinearity, and FWHM Analysis modules of the Hypermet-PC software are used for such calculations, while for the efficiency determination of larger, close-to-detector samples the Excel-based Efftran efficiency-transfer program and its macros are used.

DÖME

Figure. 1: Sample geometries at the DÖME station
  Left: off-line counting of in-beam activated samples. Right: HDPE container for environmental samples



                         Figure 2. The low-level counting chamber DÖME

     Figure 3: The absolute full-energy peak efficiency for point sources
                          at 167 mm in the DÖME counting station.

döme

                              Figure 4: Nonlinearity and energy resolution of DÖME counting station

References:

Z Kis, P Völgyesi, Z Szabó. (2013) DÖME: Revitalizing a low-background counting chamber and developing a radon-tight sample holder for gamma-ray spectroscopy measurements. J Radioanal Nucl Chem. 298(3) 2029-35. DOI: 10.1007/s10967-013-2691-8

Szentmiklósi L, Maróti B, Párkányi D, Harsányi I, Révay Z  (2018): High-energy detector calibration data for k0-neutron activation analysis. J Radioanal Nucl Chem. 315(3) 743–750
